2-way, Class D bi-amped active PA speaker
250-watt, 12" low-frequency driver
50-watt, 1.3" high-frequency Titanium compression driver
Efficient, lightweight Neodymium magnet LF driver
OptImage waveguide technology with wide dispersion angle (90 x 60 degrees)
Excellent off-axis response
Smooth, detailed mid-/high-frequency reproduction
Phase-accurate, precision-engineered 24dB/octave crossover
Durable, road-worthy cabinet design, at only 31 lbs. weight
3 handles with deep hand wells for easy transport
Unique internal port flares for tighter bass response
4 specially tuned EQ presets make it easy to dial in the right sound: Normal, Hi-Fi, DJ, and Voice
5 integrated M10 fly-points and 1.4"" pole mount for flexible positioning
Die-cast aluminum amplifier heat sink prevents overheating for extended operation

System type: active 12"", two-way bass reflex design
Frequency range: 55Hz-20kHz (-3dB points, "Normal" preset selected)
Coverage pattern: 90 H x 60 V nominal
Crossover frequency: 2.8kHz
System power rating: 300 W continuous, 600 W peak
Maximum SPL: 127dB
Nominal impedance: 8 Ohms
LF driver: 250 W continuous at driver impedance
HF driver: 50 W continuous at driver impedance
LF driver size/type: 1 x 12" (30.5 cm), Neodymium magnet with 2.5"" voice coil
HF driver size/type: 1 x 1.3" (3.3 cm), Titanium diaphragm compression driver
Highpass filter: 75Hz
Input: balanced XLR/1/4" TRS combo jack with XLR loop through
Pole socket: 36mm pole mount socket with stabilizing screw
Mounting: 5 x M10 suspension points (2 bottom, 2 top, 1 rear)
AC input: 120-240 V, 50/60Hz
Dimensions: (H x W x D) 26.3" x 16.3" x 13.5"
Weight: 31 lbs
